Status: In Stock

Kode Barang : SKU04210669

Spesifikasi :  Camera Image Sensor 1/2.8" 1080p Exmor CMOS Effective Picture Elements 2 Megapixels Output Resolutions 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50 Minimum Illumination 0.5 lux (IRE50, F1.6, 30fps) S/N Ratio ≥ 50dB Gain Auto, Manual TV Lines 900 (Center/Wide) Shutter Speed 1/1 to 1/32,000 sec Exposure Control Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR White Balance Auto, Manual, ATW, One Push Optical Zoom 12X Digital Zoom 12X Total Zoom 144X Viewing Angles DFOV : 78° (Wide) to 7° (Tele) HFOV : 70° (Wide) to 6° (Tele) VFOV : 42° (Wide) to 3° (Tele) Focal Length f = 3.9 mm (Wide) to 46.8 mm (Tele) Aperture (Iris) F = 1.6 (Wide) to 2.8 (Tele) Minimum Working Distance 0.3 m (Wide), 1.5m (Tele) Pan / Tilt Angles Pan : ±170°, Tilt : +90° / -30° Pan / Tilt Speed (Manual) Pan : 0.1° to 100° / sec, Tilt : 0.1° to 100° / sec Preset Speed Pan : 200° / sec, Tilt : 200° / sec Preset Positions 10 (IR), 256 (RS-232 / RS-422 / IP) Camera Control - Interfaces RS-232 (DIN8), RS-422 (RJ45), IP Camera Control - Protocols VISCA (RS-232 / RS-422 / IP), PELCO-D & PELCO-P (RS-232 / RS-422), CGI (IP) Image Processing Noise Reduction (2D / 3D), Flip, Mirror Power Frequencies 50 Hz, 60 Hz AI Auto Tracking Functions Tracking Modes Presenter Mode, Zone Mode, Hybrid Mode Privacy Protection Mechanism Protection Mode Sleep Mode Audio Channels 2ch Stereo Codecs AAC-LC, PCM Interface Video Outputs HDMI, IP, USB Audio Outputs HDMI, IP, USB Audio Inputs MIC in, Line in General Power Requirement AC 100 - 240V to DC 12V/5A Power Consumption 19W PoE PoE+ Dimensions (W x H x D) 180.0 x 192.0 x 145.0 mm Net Weight 2.0 (±0.1) kg Application Indoor Tally Lamp Yes Security Kensington Slot Remote Control Infrared Operating Conditions Temperature: 0°C to +40°C Humidity: 20% to 80% Storage Conditions Temperature: -20°C to +60°C Humidity: 20% to 95% IP Streaming Resolution 1080p 60fps Network Video Compress Formats H.264, H.265, MJPEG Maximum Frame Rate 1080p 60fps Bit-Rate Control Modes VBR, CBR (selectable) Range of Bit-Rate setting 512 Kbps to 32 Mbps Network Interface 10 / 100 / 1000 Base-T Multi-stream Capability 2 (RTSP / Web Page), 1080p 60fps (max.) Network Protocols IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP NDI ® |HX Capability N/A USB Connector USB 3.0 Video Formats MJPEG, YUY2 Maximum Video Resolution 1080p USB Video Class (UVC) UVC 1.1 USB Audio Class (UAC) UAC 1.0 Web UI Live Video Preview Yes Camera PTZ Control Pan, Tilt, Zoom, Focus, Preset Control Camera / Image Adjustment Exposure, White Balance, Picture Network Configuration DHCP, IP Address, Gateway, Subnet Mask, DNS Software Tools IP Search & Configuration Tool Support Windows® 7 or later PTZ Management Support Windows® 7 or later PTZ Control Panel Supports iOS & iPadOS® 11 or later PTZ Link Support Windows® 7 or later, macOS® 10.14 or later OBS Plugin for PTZ Cameras Support Windows® 8 or later, macOS® High Sierra v10.13 or later CaptureShare Support Windows® 7 or later, macOS® 10.14 or later Warranty Camera 3 Years Accessories 1 Year Package Contents Camera, Drilling Paper, Ceiling Mount Bracket (x2) Quick Start Guide, Cable Fixing Plate, M2 x 4 mm Screw (x3), Power Adapter & Power Cord, 1/4"-20 L=6.5 mm Screw (x2), Remote Control, M3 x 6 mm Screw (x3), DIN 8 to D-Sub 9 Cable, RS-232 In/Out Y Cable, Cable Ties (x4) Optional Accessories AVer CL01 PTZ Camera Controller, L-Type Wall Mount
